Specification of 1050 Aluminum Strip
Width: 10mm-1500mm
Thickness: 0.1mm-3.0mm
Grade: 1000 Series
Temper: O - H12
Application: Decoration
Standard: GB/T3190-1996
Main features and scope of application:
Industrial pure aluminum has the characteristics of high plasticity, corrosion resistance, electrical conductivity and thermal conductivity, but the strength is low, it is not strengthened by heat treatment, the machinability is not good, and contact welding and gas welding are acceptable. Make use of its advantages to make structural parts with specific properties, such as aluminum foil for gaskets and capacitors, tube isolating nets, protective covers for wires and cables, nets, wire cores and aircraft ventilation system parts and ornaments.
Mechanical properties:
Tensile strength σb (MPa)95～125
Conditional yield strength σ0.2 (MPa)≥75
Introduction of our company
Gongyi Shengzhou Metal Products Co.,Ltd. is a professional Aluminium Strip Suppliers and Aluminum Circles manufacturers,mainly supply Aluminum Circles, Aluminium discs, Aluminum Strip, Food Box Material Aluminum Foil, Aluminum Circles for Kitchenware etc. series of aluminum products, sincerely welcome everyone to visit.
Technical Parameters of 1050 Aluminum Strip
Model |
1050 Aluminum strip |
Thickness ( mm) |
0.1 - 3.0 mm |
Width ( mm) |
10 - 1500 |
Grade |
1050 |
Temper |
O - H12
|
Standard: |
GB/T3190-1996
|
Tensile strength σb (MPa) |
95～125 |
Conditional yield strength |
σ0.2 (MPa)≥75 |
Chemical Composition of 1050 Aluminum Strip
Specifications |
1050 Aluminum strip | |
| Chemical composition% | Al | 99.50 |
| Si | 0.25 | |
| Cu | 0.05 | |
| Mg | 0.05 | |
| Zn | 0.05 | |
| Mn | 0.05 | |
| Ti | 0.03 | |
| V | 0.05 | |
| Fe | 0.40 | |
| Other | 0.03 |
|
